25G WDM SFP

25G LWDM/DWDM SFP28

WDM SFP is an optical transceiver that utilizes Wavelength Division Multiplexing technology.

Recently, the use of wavelength division multiplexing (WDM) in mobile front-haul networks has attracted attention because of the advantages of wider bandwidth and reduced use of optical fiber. With WDM, it is possible to transmit multiple wavelengths simultaneously, enabling high-capacity transmission over a single fiber.

NEC offers products that support DWDM in the C-band and products capable of long-distance transmission in the O-band, tailored to meet customers' needs.

NEC contributes to the WDM implementation in customers' networks with 25G WDM SFP.

Features

  • WDM application for mobile fronthaul
  • O-band / C-band

Specifications

Bitrate Part Number Wavelength Reach Mux Power consumption Operating
Case Temp.
25.7Gb/s OD-CP103FSL0xxx O-band 12ch 10km LWDM filter 1.8W -40 to +85℃
25.7Gb/s OD-CP103FLL0xxx O-band 8ch 30km LWDM filter 2.0W -40 to +85℃
25.7Gb/s OD-CP103ESL0xxx C-band 44ch 10km DWDM filter 2.5W -40 to +85℃

Application
