25G SFP28 BiDi

25G SFP28 BiDi LR/ER/ZR/BR10/BR40

The NEC’s 25G SFP28 BiDi optical transceiver is compatible with the mobile front-haul network, enabling high-capacity and ultra-low-latency 5G communication. This module can transmit data up to a maximum of 25 gigabits and can be easily installed even in limited installation spaces due to its compact design. By enabling bidirectional transmission over a single fiber, this module enhances fiber utilization efficiency and can reduce fiber installation costs and fiber rental costs.

We offer a diverse range of options that support transmission distances of 10km, 40km, and 60km respectively. With these features, NEC's 25G SFP28 BiDi products contribute significantly to customer needs.

Features

  • Bidirectional transmission of 25Gb/s
  • Wide operating temperature range
  • Low power consumption
  • The transmission distance ranges from 10km to 60km
  • OD-BP1037ZL0001/OD-BP1038ZL0001 supports a link budget of 25dB

Specifications

Bitrate Part Number Form Factor Wavelength Reach Power consumption Operating Case Temp.
25.7Gb/s OD-BP1031SL1001
OD-BP1033SL1001
SFP28 1270nm/1330nm 10km 1.3W -40 to+85℃
25.7Gb/s OD-BP1032SL0001
OD-BP1034SL0001
SFP28 1270nm/1310nm 10km 1.3W -40 to+85℃
25.7Gb/s OD-BP1035ZL1001
OD-BP1036ZL1001
SFP28 1289nm/1314nm 40km 2.0W -40 to+85℃
25.7Gb/s OD-BP1032LL0001
OD-BP1034LL0001
SFP28 1270nm/1310nm 40km 2.0W -40 to+85℃
25.7Gb/s OD-BP1037ZL0001
OD-BP1038ZL0001
SFP28 1295nm/1309nm 60km 2.5W -40 to+85℃

Application
