VersaPro type VB (2016 Model) : Specifications

  VersaPro type VB (2016 Model)
Product code VG23T/B-T
Installed OS Windows 10 Pro 64-bit (English)
CPU Intel® Core™ i5-6200U processor *1 *2
  Clock speed
(at Max turbo frequency)
2.30 GHz (2.80 GHz max.)
Number of cores/threads 2/4
L3 cache memory 3 MB
Memory bus 2,133 MHz
Chipset (Integrated with CPU)
Security chip TPM (TCG v.1.2), Intel® PTT (TPM 2.0 compliant). Integrated in CPU *41 [exclusive specification]
Maximum memory (main memory) Max. 16 GB (4 GB DDR4-SDRAM, PC4-17000, 4,096 MB SO-DIMM x 1) *28
Display LCD Can select from 12.5-inch wide TFT color IPS LCD (Full HD: 1,920 x 1,080 dot LED backlight, non-glare)
or 12.5-inch wide TFT color LCD (HD: 1,366 x 768 dot LED backlight, non-glare)
Graphics accelerator Intel® HD Graphics 520 (built into CPU, with dual display support and smoothing function)
Display
colors
(resolution)
Built-in
display
*11
*13
HD LCD Max. 16.77M colors (1,366 × 768 [HD], 1,280 × 720 [HD], 1,024 × 768 [XGA], 800 × 600 [SVGA])
Full HD LCD Max. 16.77M colors (1,920 × 1,080 [Full HD], 1,680 × 1,050 [WSXGA+], 1,600 × 900 [HD+],
1,366 × 768 [HD], 1,280 × 720 [HD], 1,024 × 768 [XGA], 800 × 600 [SVGA])
Audio source and sound Built-in stereo speakers, compliant with Intel® High definition Audio standard (stereo PCM sound reproduction
function, software MIDI sound source)
Communication LAN 1000BASE-T/100BASE-TX/10BASE-T, Remote Power On (Wake on LAN) functions supported
Wireless LAN IEEE802.11ac, EEE802.11a/b/g/n compliant, Wi-Fi Direct™ compliant, Miracast®
Bluetooth® Bluetooth® Smart Ready (Ver.4.1)
Input devices Keyboard English keyboard (key pitch: 18 mm; key stroke: 1.8 mm)
Pointing devices NX pad with integrated click buttons and multitouch/gesture functions
Web camera HD resolution (720P) camera, 920,000 effective pixels
Microphone Stereo microphone
Interfaces USB USB 3.0 (left side x 2, right side x 1 (with power-off USB charging feature))
Display HDMI port × 1, Mini Display Port × 1
Communication RJ45 LAN connector × 1
Sound Both input and output: headphone/headphone microphone jack x 1
Memory card slot SD (SDHC/SDXC) memory card slot × 1 *22
Power supply Battery or AC 100 V to 240 V ±10%, 50/60 Hz (via AC adapter)
Maximum power consumption Approx. 45 W
Battery 6-cell, lithium-ion battery L (DC 10.8 to 11.22 V, 72 Wh *49)
Dimensions (excluding protrusions) 305.5 (W) × 208.5 (D) × 32.3 (H) mm
Weight (including battery) Full HD LCD: Approx. 1.41 kg, HD LCD: 1.45 kg
Temperature and humidity conditions 5 to 35°C, 8 to 95% (non-condensing)
OS for which drivers are supplied *27 Windows 10 Pro 64-bit / Windows® 7 Professional 64-bit (SP1)
Main accessories Compact and lightweight AC adapter etc.
Selection menu
Display
elements
HD Resolution: Max. 1,366 × 768 dots
Full HD Resolution: Max. 1,920 × 1,080 dots
Storage 500GB HDD Approx. 500 GB *56, Serial ATA/600, 7,200 rpm, SMART functions supported
256GB SSD
with encryption function
Approx. 256 GB *56, Serial ATA/600, SMART functions supported, with encryption function

Additional specifications for each country model

Asia-Pacific model

Safety standards Complies with IEC60950-1
EMC CE,MIC
Wireless LAN IDA, SDPPI, SIRIM, MIC, NTC
Battery TISI
AC adapter PSB, ST
