VersaPro type VB: Notes Concerning Detailed Specifications

Japanese

Back

  • *1:Simplified Chinese OS models are only sold in China.
  • *2:Japanese OS models are not sold in Japan.
  • *3:Supports hyperthreading technology. Enhanced Intel SpeedStep® technology driver is built in.
  • *4:The pre-installed 4 GB memory cannot be removed. Up to 8 GB of memory can be installed, but not all memory area can be used by a 32-bit OS. Even if memory of 4 GB or more is installed, only 3 GB can be used by the OS. The memory capacity that can be used differs according to the device configuration.
  • *5:The 16.77M-color display is realized by the dithering features of the graphics accelerator.
  • *6:The built-in wireless LAN module has received Wi-Fi® certification from the Wi-Fi Alliance industry group. Communication is possible only between devices that use the same WiFi standard.
  • *7:The maximum speed in theory is 300 Mbps for both transmission and reception, but the actual data transfer speed you experience will vary. The communication speed and communication distance may be affected by the connected device, EM environment, surrounding obstructions, the installat ion environment, usage conditions, application software used, OS, and so on. The speed when connected will differ according to the specifications of the connected 11n wireless LAN device.
  • *8:The communication speed and distance are affected by the operating environment. IEEE 802.11b/g (2.4 GHz) is not compatible with IEEE 802.11a (5 GHz).
  • *9:The communication speed will vary depending on the line conditions. The built-in fax modem can only use general subscriber telephone lines.
  • *10:56 kbps is the maximum speed when receiving data. The maximum speed when transmitting data is 33.6 kbps.
  • *11:The area that can be used by the customer is 1 partition (which is pre-formatted to NTFS). Also, about 8 GB of the HDD is used to store the backup image for reinstallation.
  • *12:Supports the acceleration sensor incorporated in this product.
  • *13:This feature is designed to reduce the possibility of damage to the HDD if the computer is dropped; it does not guarantee absolute protection.
  • *14:Does not support copyright protection. A SDIO card cannot be used.
  • *15:The battery drive time and charging time might vary from the figures given here, depending on the usage conditions. The battery pack degrades over time.
  • *16:When no optical drive is attached and PC and SD cards are not inserted.
  • *17:This is the weight in the lightest configuration. The weight increases as follows: by about 140 g when a lithium-ion battery is included; by about 100 g when an optical drive is included.
  • *18:An optical drive is required to use the reinstallation media.
  • *19:The countries in which the fax modem can be used are listed below.
  • *20:This device can use only PC cards whose I/O addresses are set to or can be changed to 1000h or higher.
  • *21:Only one SO-DIMM slot can be accessed by the user.
  • *22:If a resolution that is lower than the resolution of the display element (main unit LCD) is selected, images can be displayed in full-screen mode by using the maximize window feature. Note that maximizing the window might cause the thickness of lines in characters and figures to become uneven.
  • *23:An external speaker or a display with an internal speaker is required to play back the audio source. (For main unit line output port)
  • *24:When playing back copyright-protected content on this computer and displaying it on a device connected to the HDMI port, the connected device must comply with the HDCP standard. If a device that does not comply with the HDCP standard is connected to this computer, protected content cannot be played back or displayed. This computer does not support the Consumer Electronics Control (CEC) feature of the HDMI standard. This computer does not support device control via the HDMI cable. It is recommended to use an HDMI cable that is 1.5 m or shorter. Depending on the usage environment, the drawing feature might not be able to be used unless the refresh rate is set to 60 Hz (progressive) or the resolution is lowered. This computer does not support underscan. Not all HDMI-compliant external displays and televisions have been verified to operate with this computer. Some HDMI-compliant external displays and televisions might not display correctly.
  • *25:Not included in China models at shipment.
  • *26:Complying with “CIRCULAR, No.30/2011/TT-BCT (Hanoi, August 10 2011), Temporary regulations on content limit for certain hazardous substances in electrical products

VersaPro type VB: Countries in which fax modem can be used

Japan, China, Singapore, Indonesia, Vietnam, Thailand, Malaysia (As of November 2012)

  • *:Do not use the built-in fax modem in countries other than those listed above.
  • *:Turn the wireless LAN feature off when using an NEC laptop PC that supports wireless LAN outside of the designated countries to avoid inadvertently breaking the law of the country you are in.
  • *:When running an NEC laptop PC designed for a certain sales area on AC power in another area or country, you will require a power cord that complies with the AC power specifications of the country you are in.
  • *:You might require certification to take an NEC laptop PC designed for a certain sales area to another area or country. It is your responsibility to acquire the correct certification when traveling with your NEC laptop PC.
  • *:See NEC Ultracare for details about our overseas warranty service. (This is a service through which customers can have certain notebook computers that were purchased in Japan and are still within the warranty period repaired while they are traveling overseas.)
